Handlebar Thomson 730mm Carbon Rise

The Thomson Rise Carbon handlebar is a carbon fiber bar for the Mountain Bike enthusiast. A rise bar with a rise of 15mm and 6° of backsweep for comfort. 750mm in width for plenty of leverage.

Bars are made with three different fiber types with different tensile strength and tensile modulus, including High Strength carbon fibers. This helps to allocate stiffness and flex where needed.

The Thomson Carbon bars are molded with an EPS mandrel inside to avoid wrinkles inside the layup during molding. Most other bars are molded over inflated nylon bladders.

All carbon fiber material is produced by Toray and uses tailor made nano Epoxy Resin for very high impact resistance. Toray is the main supplier of carbon fiber to Boeing and Airbus.

1.5K woven impact ends help prevent damage to unidirectional fibers from shortening the bar or impact with the ground.

Light weight, precision tolerance clamp sections. Certified to EN, tested to DIN+.

The best bar for your Thomson X4 stem.

• Model Number: HB-E117.
• Handlebar Description: 750mm x 15mm rise x 8° backsweep x 31.8 diameter.
• Weight: 215gr.
